Overview - Fresh Air Intake
WARNING: This page is about a different variant/trim than selected.
Depending on the vehicle version, there are different fresh air intake versions. Refer to the Parts Information.
- Humidity Sensor in Fresh Air Intake Duct -G657- / Air Quality Sensor -G238-
- Different versions (with or without Air Quality Sensor -G238-) depending on the version of the A/C system. Refer to the Parts Information.
- Humidity Sensor in Fresh Air Intake Duct -G657- /Air Quality Sensor -G238-, REMOVING AND INSTALLING
- Fresh Air Intake Grille
- Depending on the version and market, a dust filter might be installed in the filter mount instead of the grille. For the allocation, refer to the Parts Information.
- Fresh Air Intake Cover
- Expanding Clip
- Quantity: 2
- Fresh Air Intake
- With seal to the plenum chamber rear panel
- Refer to FRESH AIR INTAKE, REMOVING AND INSTALLING
- Plate
- Nut
- 3.5 Nm
- Tightening sequence. Refer to FRESH AIR INTAKE, REMOVING AND INSTALLING .
- Quantity: 3
