Overview - Side Marker Lamp

WARNING: This page is about a different car, the 2024 Audi SQ7, 2024 Audi Q7, 2023 Audi SQ7, and 2023 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Side Marker Lamp

Courtesy of AUDI

Tail Lamp
- There are different versions. Refer to the appropriate Electronic Parts Information.
- Removing and Installing. Refer to LOWER TAIL LAMP, REMOVING AND INSTALLING .
Rear Side Marker Lamp Bulb
- Left Rear Side Marker Lamp Bulb -M37-
- Right Rear Side Marker Lamp Bulb -M38-
- 12V, 3 W (W3W)
- Bulb, Replacing. Refer to REAR SIDE MARKER LAMP BULB, REMOVING AND INSTALLING .
Bulb Socket
Headlamp Housing
- Removing and Installing. Refer to HEADLAMP HOUSING, REMOVING AND INSTALLING .
Front Side Marker Lamp Bulb
- Left Front Side Marker Lamp Bulb -M33-
- Right Front Side Marker Lamp Bulb -M34-
- Cannot be replaced separately
- Replace the headlamp housing if faulty.
Bolt
- Tightening specification -item 18- OVERVIEW - BODY TAIL LAMPS.
Cap
- For the bolt
- In the bumper cover
