Center Instrument Panel Ambient Lighting Lamp -L231-, REMOVING AND INSTALLING: Removing
WARNING: This page is about a different car, the 2022 Audi SQ7 and 2022 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the lower front passenger side instrument panel decorative trim -2-. Refer to INSTRUMENT PANEL DECORATIVE TRIM, REMOVING AND INSTALLING .
This is disassembled to remove the faulty LED module.
-- Release the retainers in direction of -arrows-, and remove the cover -6-.
-- Remove the circuit board -1-.
-- Release the retainers -3 and 5- and remove the housing -2- from the fiber-optic cable -4-.
