Overview - Camshaft Housing

WARNING: This page is about a different car, the 2022 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.

All components are described. Refer to OVERVIEW - CAMSHAFT HOUSING .

Engine Cover Bracket - Tightening Specification

Fig 1: Engine Cover Bracket

Courtesy of AUDI OF AMERICA, LLC

-- Tighten the bolts -arrows- to 9 Nm.

NOTE:

Ignore -1, 2 and 3-.
