Tail Pipe Trim, Removing And Installing, S6 TDI And S7 TDI SPORTBACK: Removing

WARNING: This page does not describe the selected car, but rather 10 other vehicles, including the 2022 Audi RS 7 Sportback, 2022 Audi A7 e Quattro, 2022 Audi A7 Quattro, 2021 Audi S7, and 2021 Audi RS 7 Sportback. However, it is still accessible from the selected car via links, so may be relevant.

-- Right: remove the rear underbody trim panel. Refer to OVERVIEW - UNDERBODY TRIM PANELS .

-- Release the retainers -arrows-.

GWWA63-11724Courtesy of AUDI OF AMERICA, LLC

-- Remove the tail pipe trim -1- forward.
