Overview - High-Mounted Brake Lamp, A7 SPORTBACK

WARNING: This page does not describe the selected car, but rather 10 other vehicles, including the 2022 Audi RS 7 Sportback, 2022 Audi A7 e Quattro, 2022 Audi A7 Quattro, 2021 Audi S7, and 2021 Audi RS 7 Sportback. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of High-Mounted Brake Lamp

Courtesy of AUDI OF AMERICA, LLC

Clip Nut
- Quantity: 2
High-Mounted Brake Lamp
- High-Mounted Brake Lamp Bulb -M25-
- Removing and Installing. Refer to HIGH-MOUNTED BRAKE LAMP BULB, REMOVING AND INSTALLING, A7 SPORTBACK .
Seal
- Replace after removing
- Quantity: 5
Nut
- Tightening sequence. Refer to Fig 2.
- Quantity: 5

High-Mounted Brake Lamp Bulb - Tightening Specification and Sequence

Fig 2: High-Mounted Brake Lamp Bulb Tightening Sequence

Courtesy of AUDI OF AMERICA, LLC

-- Tighten the nut to 2.5 Nm in the following sequence: -1 to 5-.
