Wheel Bearing Housing, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2022 Audi SQ7, 2022 Audi Q7, 2021 Audi SQ7, 2021 Audi Q7, and 2020 Audi SQ7. However, it is still accessible from the selected car via links, so may be relevant.

Vehicles with active suspension: pay attention to the safety precautions. Refer to SAFETY PRECAUTIONS WHEN WORKING ON VEHICLES WITH ACTIVE SUSPENSION .

-- Loosen the connection between the drive axle and wheel hub. Refer to DRIVE AXLE THREADED CONNECTION, LOOSENING AND TIGHTENING .

-- Remove the brake shield. Refer to BRAKE SHIELD, REMOVING AND INSTALLING .

-- Disconnect the connector -1- for the rear speed sensor.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolt -1- and free up the bracket -2- with the wires.

Courtesy of AUDI OF AMERICA, LLC

-- Install the Support Device :VAS 6931/1 -item A- to the brake rotor -1- using two wheel bolts -2-.

Courtesy of AUDI OF AMERICA, LLC

-- Position the Engine and Gearbox Jack :VAS 6931 -item B- to the support bridge.

CAUTION:

There is a risk of an accident when lowering the vehicle when the engine and gearbox jack is underneath it.

- Never lower the vehicle when the engine and gearbox jack is underneath it.

- Never leave the engine and gearbox jack under the vehicle any longer than necessary.

-- Slightly lift the wheel bearing housing using the Support Device :VAS 6931/1 with the Engine and Gearbox Jack :VAS 6931 this allows the threaded connections to easily separate.

-- Remove the screw -2- and disconnect the threaded connection -1-.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -3 and 4- and disconnect the connector -1-.

Courtesy of AUDI OF AMERICA, LLC

-- Loosen the wheel bearing housing -2- from the drive axle and remove it.
