Bumper Carrier, Removing And Installing: Removing

-- Remove the bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .

-- Disconnect the connectors -1 and 3- and free up the wiring harness -2-.

Courtesy of AUDI OF AMERICA, LLC

-- For reinstallation, mark the installation position -3- of the lock carrier on both sides of the lock carrier.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -arrows-.

-- Pull the bumper carrier -1- forward and push it downward.

• At the same time the bumper carrier is disengaged upward from the guide -2-.

-- Remove the bumper carrier.
