Central Valve, Removing And Installing: Removing
WARNING: This page is about a different variant/trim than selected.
The central valves are attached to the impact member under the bumper cover in the rear.
-- Loosen the lower rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
WARNING:
Risk of eye injury.
- Wear protective eyewear!
NOTE:
The DRC lines must be extracted before disconnecting them from the central valve. Refer to DYNAMIC RIDE CONTROL (DRC), DRAINING AND FILLING .
Perform this step on both wiring harnesses on the central valve.
-- Remove the union bolts -1-.
-- Remove the bolts -2- and remove the central valve -3-.
