Overview - Tower Brace
WARNING: This page is about a different variant/trim than selected.
- Right Suspension Strut Tower
- Bolt
- 20 Nm
- Right Tower Brace
- A5 Cabriolet: one piece with the left tower brace
- Removing and installing. Refer to TOWER BRACE, REMOVING AND INSTALLING .
- Sealing Piece
- Nut
- 20 Nm
- Bulkhead
- Left Tower Brace
- A5 Cabriolet: one piece with the right tower brace
- Sealing Piece
- Bolt
- 20 Nm
- Left Suspension Strut Tower
- Nut
- 20 Nm
