Overview - Rear Lid Release
WARNING: This page is about a different variant/trim than selected.
- Emergency Release Cable Loop
- On the seat pan for the rear bench seat
- Emergency Release Cable
- Only for a fixed backrest
- Release Cable Bracket
- With locking mechanism
- Release Cable Bracket
- Open
- Bracket
- For the seat belt
- Release Cable Bracket
- With locking mechanism
- Release Cable to Latch
- Release Cable Bracket
- Open
- Latch
- Rear Lid Lock Unit -VX25-
- With Rear Lid Central Locking System Motor -V53-, Lock Pawl Contact Switch -F443-, equipped on some models: Rear Lid Contact Switch -F111-
- Removing and Installing. Refer to LATCH, REMOVING AND INSTALLING .
- Nut
- 21 Nm
- Quantity: 2
- Rear Lid Latch Trim Panel
- Removing and Installing. Refer to REAR LID LOWER TRIM PANEL, REMOVING AND INSTALLING .
- Nut
- 8 Nm
- Quantity: 2
- Striker
- Removing and Installing. Refer to STRIKER, REMOVING AND INSTALLING .
- Adjusting. Refer to HEIGHT ADJUSTMENT AT STRIKER .
- Floor Panel
- Rear Bench Seat
- Velcro Strip
- For securing the emergency release cable loop
