Overview - Side Trim Panel Lamps
WARNING: This page is about a different variant/trim than selected.
- Left Rear Door Storage Compartment Illumination Lamp -L257- in the Side Trim Panel
- Removing and installing. Refer to RIGHT/LEFT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP -L258- / -L257-, REMOVING AND INSTALLING, SIDE TRIM PANEL .
- Fiber-Optic Cable for Ambient Lighting in Side Trim Panel - Left
- Removing and installing. Refer to FIBER-OPTIC CABLE FOR AMBIENT LIGHTING IN SIDE TRIM PANEL, REMOVING AND INSTALLING, COUPE .
- Left Rear Door Ambient Lighting Bulb 1 -L201- in the Side Trim Panel
- Removing and installing. Refer to LEFT/RIGHT REAR DOOR AMBIENT LIGHTING BULB 1 -L201- / -L202- IN SIDE TRIM PANEL, REMOVING AND INSTALLING, COUPE .
- Right Rear Door Storage Compartment Illumination Lamp -L258- in the Side Trim Panel
- Removing and installing. Refer to RIGHT/LEFT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP -L258- / -L257-, REMOVING AND INSTALLING, SIDE TRIM PANEL .
- Fiber-Optic Cable for Ambient Lighting in Side Trim Panel - Right
- Removing and installing. Refer to FIBER-OPTIC CABLE FOR AMBIENT LIGHTING IN SIDE TRIM PANEL, REMOVING AND INSTALLING, COUPE .
- Right Rear Door Ambient Lighting Bulb 1 -L202- in the Side Trim Panel
- Removing and installing. Refer to LEFT/RIGHT REAR DOOR AMBIENT LIGHTING BULB 1 -L201- / -L202- IN SIDE TRIM PANEL, REMOVING AND INSTALLING, COUPE .
