Overview - Center Armrest
WARNING: This page is about a different variant/trim than selected.
- Cupholder
- Removing and Installing. Refer to CENTER ARMREST CUPHOLDER, REMOVING AND INSTALLING .
- Install and press on it until it audibly latches
- Cupholder Trim
- Left and right sides are shaped differently
- Center Armrest
- Removing and Installing. Refer to CENTER ARMREST, REMOVING AND INSTALLING .
- Bolt
- 5 Nm
- Hinge Pin
- Hinge Trim
- Center Rear Seat Backrest
- Removing and Installing. Refer to CENTER REAR SEAT BACKREST, REMOVING AND INSTALLING, A5 COUPE/SPORTBACK .
- Thrust Washer
- Thrust Washer
- Washer
- Bolts
- 3.5 Nm
