Overview - Front Backrest, Neck Heating
WARNING: This page is about a different variant/trim than selected.
- Neck Heating
- Left Neck Heating Fan -V450-
- Right Neck Heating Fan -V451-
- Removing and Installing. Refer to LEFT AND RIGHT NECK HEATING FAN .
- Engage on the backrest frame
- Air Duct
- Clipped into the neck heating
- Press on until it engages audibly
- Headrest Trim
- With neck heating vent
- Removing and Installing. Refer to HEADREST, REMOVING AND INSTALLING .
- Clipped to the mount
- Press on until it engages audibly
- Clips
- Insert in the headrest trim
- Quantity: 4
- Bolt
- 3.5 Nm
- Quantity: 2
