Overview - Seat Belt Positioning Motor, A5 Coupe

WARNING: This page is about a different variant/trim than selected.
Fig 1: Exploded View Of Seat Belt Positioning Motor, A5 Coupe
GWWA69-11294Courtesy of AUDI OF AMERICA, LLC
  1. Steering Rack
    • Available only together with -2-
  2. Seat Belt Positioner
  3. Bolt
    • 1.5 Nm
    • Quantity: 4
