Overview - Wind Deflector
WARNING: This page is about a different variant/trim than selected.
- Latching Element
- Included in the repair kit
- Quantity: 2
- Pressure Spring
- Included in the repair kit
- Quantity: 4
- Clip
- Included in the repair kit
- Unclip using a screwdriver
- Clip into the wind deflector
- Wind Deflector Mount
- Removing and Installing. Refer to WIND DEFLECTOR MOUNT, REMOVING AND INSTALLING .
- Clip into the side trim panel
- Quantity: 2
- Front Bearing
- Included in the repair kit
- Clip into the wind deflector
- Quantity: 2
- Wind Deflector
- Perform the repair procedure. Refer to WIND DEFLECTOR, SERVICING .
- Stop Buffer
- Included in the repair kit
- Unclip using a screwdriver
- Clip into the wind deflector
- Quantity: 2
- Rear Bearing
- Included in the repair kit
- Clip into the wind deflector
- Quantity: 2
- Bolt
- 0.9 Nm
- Included in the repair kit
- Quantity: 2
