Overview - Windshield Frame - Trim Panel
WARNING: This page is about a different variant/trim than selected.
- Windshield Frame-Trim Panel
- Removing and Installing. Refer to WINDSHIELD FRAME-TRIM PANEL, REMOVING AND INSTALLING .
- Press on until it engages audibly
- Stop
- For the sun visor
- Insert in the trim panel
- Clip
- Replace damaged or deformed clips
- Clip into the trim panel
- Remove any remaining clips in the body mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Quantity: 8
- Trim
- Clip into the trim panel
- For the Anti-Theft Alarm System Sensor -G578-
