Overview - Rear Lid Trim Panel, A5 SPORTBACK
WARNING: This page is about a different variant/trim than selected.
- Clip
- Replace damaged or deformed clips
- Insert in the trim panel
- Remove any clips remaining in the rear lid mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- On the side, quantity: 6
- Protective Cap
- Quantity: 2
- Mount
- For luggage compartment cover
- Quantity: 2
- Expanding Clip
- Remove using the Pliers: T40172C
- Quantity: 2
- Cover
- For the tail lamp
- Removing and Installing. Refer to TAIL LAMP COVER, REMOVING AND INSTALLING .
- Clip into the rear lid trim panel
- Press on until it engages audibly
- Quantity: 2
- Clip
- Replace damaged or deformed clips
- Insert in the trim panel
- Remove any clips remaining in the rear lid mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Quantity: 12
- Rubber Buffer
- Insert in the trim panel
- Quantity: 7
- Rear Lid Latch Trim Panel
- Removing and Installing. Refer to REAR LID LOWER TRIM PANEL, REMOVING AND INSTALLING, A5 SPORTBACK .
- Press on until it engages audibly
- Rear Lid Lower Trim Panel
- Removing and Installing. Refer to REAR LID LOWER TRIM PANEL, REMOVING AND INSTALLING, A5 SPORTBACK .
- Press on until it engages audibly
- Emergency Release Cover
- Unclip using the Trim Removal Wedge: 3409
- Clipped in the rear lid trim panel
- Press on until it engages audibly
- Rear Lid Upper Trim Panel
- Removing and Installing. Refer to REAR LID UPPER TRIM PANEL, REMOVING AND INSTALLING .
- Press on until it engages audibly
- Rubber Buffer
- Insert in the trim panel
- Quantity: 4
- Clip
- Replace damaged or deformed clips
- Insert in the trim panel
- Remove any clips remaining in the rear lid mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Top, quantity: 5
