Overview - Luggage Compartment Side Trim Panel, A5 Coupe
WARNING: This page is about a different variant/trim than selected.
- Clip
- Replace damaged or deformed clips
- Insert in the trim panel
- Remove any clips remaining in the mounting points using the Omega Clip Tool: T40280 and insert them into the trim panel for installation.
- Quantity: 4
- Tie Down Bracket
- Removing and Installing. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING, A5 COUPE .
- Trailer Hitch Button Trim
- Equipped on some models
- Removing and Installing. Refer to OVERVIEW - CONTROLS IN LUGGAGE COMPARTMENT .
- Clip
- Replace damaged or deformed clips
- Insert in the trim panel
- Remove any clips remaining in the mounting points using the Omega Clip Tool: T40280 and insert them into the trim panel for installation.
- Quantity: 2
- Lid Hinge Frame
- Removing and Installing. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING, A5 COUPE .
- Engage in the trim panel and press on it until it engages audibly
- Bolt
- 1.8 Nm
- Quantity: 2
- Expanding Nut
- Clip into the body
- Quantity: 2
- Bag Hooks
- Removing and Installing. Refer to BAG HOOK, REMOVING AND INSTALLING .
- Expanding Clip
- Remove using the Pliers: T40172C
- Quantity: 2
- Luggage Compartment Side Trim Panel
- Removing and Installing. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING, A5 COUPE .
- Press on until it engages audibly
- Stretch the lip of the rear lid seal over
- Bolt
- 9 Nm
- Quantity: 2
- Tie Down
- Removing and Installing. Refer to TIE DOWN, REMOVING AND INSTALLING .
- Quantity: 2
- Lock Carrier Trim Panel
- Removing and Installing. Refer to LOCK CARRIER TRIM PANEL, REMOVING AND INSTALLING .
- Must engage in the pins
- Press on until it engages audibly
- Stretch the lip of the rear lid seal over
