Overview - Convertible Top Compartment Trim Panel
WARNING: This page is about a different variant/trim than selected.
- Side Trim Panel
- For the convertible top compartment
- Removing and Installing. Refer to CONVERTIBLE TOP COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING .
- Quantity: 2
- Expanding Clip
- Remove using the Pliers: T40172C
- Quantity: 3
- Expanding Clip
- Remove using the Pliers: T40172C
- Quantity: 4
- Center Trim Panel
- For the convertible top compartment
- Removing and Installing. Refer to CONVERTIBLE TOP COMPARTMENT CENTER TRIM PANEL, REMOVING AND INSTALLING .
- Clip
- Replace damaged or deformed clips
- Remove the clips that are still in the mounting points on the body using the Omega Clip Tool: T40280 .
- Insert in the trim panel
- Quantity: 4
- Clip
- Replace damaged or deformed clips
- Remove the clips that are still in the mounting points on the body using the Omega Clip Tool: T40280 .
- Insert in the trim panel
