Overview - Adjusting Element

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2022 Audi S5 Sportback, 2022 Audi S5, 2022 Audi RS 5 Sportback, 2022 Audi A5 Sportback, and 2021 Audi S5 Sportback. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Adjusting Element
GWWA50-11210Courtesy of AUDI OF AMERICA, LLC
  1. Balance Weight
  2. Nut
    • 24 Nm
    • Quantity: 2
  3. Left Longitudinal Member
  4. Nut
    • 24 Nm
    • Quantity: 2
