Front Belt End Fitting, Removing And Installing: Removing

WARNING: This page is about a different car, the 2022 Audi RS 6 Avant and 2021 Audi RS 6 Avant. However, it is still accessible from the selected car via links, so may be relevant.

-- Move the front seat all the way forward and up.

-- Remove the B-pillar lower trim panel. Refer to B-PILLAR LOWER TRIM PANEL, REMOVING AND INSTALLING .

Belt end fitting without seat belt tensioner:

Courtesy of AUDI OF AMERICA, LLC

-- Push the carpet in the threaded connection area to the side and remove the bolt -1-.

-- Remove the bolt with the belt anchor -2-.

Belt end fitting with seat belt tensioner:

Courtesy of AUDI OF AMERICA, LLC

-- Push the carpet in the belt end fitting area to the side.

-- Remove the bolt -1- and then remove the belt relay -2-.

-- Disengage the belt end fitting -3- from the bracket.

-- Open the cover -2- for the belt end fitting -1- with a flat-head screwdriver on the catch -arrow-, open and push to the side.

Courtesy of AUDI OF AMERICA, LLC

-- Push together the catches on the clamp with a plies -A arrows-.

Courtesy of AUDI OF AMERICA, LLC

-- At the same time push the anchoring pins -2- together with the clamp -3- to release in the direction of -arrow B-.

-- Disengage the anchoring pins from the clamp in the belt end fitting -1-.
