ELECTRICAL COMPRESSOR WITH Electric Compressor Control Module -J1123-, REMOVING AND INSTALLING: Removing

-- De-energize the 48 Volt system. Refer to BATTERY, DISCONNECTING AND CONNECTING .

-- Remove the A/C compressor from the bracket and tie it up on the left side. Refer to A/C COMPRESSOR, REMOVING AND INSTALLING FROM BRACKET .

-- Remove the left engine support. Refer to ENGINE SUPPORT, REMOVING AND INSTALLING .

-- Loosen the hose clamps -arrow- and remove the air duct hoses.

Courtesy of AUDI OF AMERICA, LLC

-- Clamp off the coolant hoses using the :3094  .

-- Loosen the hose clamps -1- and remove the coolant hoses.

-- Disconnect the connectors -2 and 4-.

-- Remove the vacuum hose -3- without damaging it.

-- Loosen the hose clamp -1-.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -arrows- and remove the electrical compressor -2-.
