Overview - Coolant Valves

Fig 1: Overview - Coolant Valves
GWWA19-13263Courtesy of AUDI OF AMERICA, LLC
  1. Bolt
    • 9 Nm
  2. Coolant Hose
  3. Transmission Fluid Cooling Valve -N509-
  4. Bracket
    • For Transmission Fluid Cooling Valve -N509-
  5. Coolant Hose
