Screen Separator Bracket, Removing And Installing: Installing

Fig 1: Installing Front Lifting Eye -2-

Courtesy of AUDI OF AMERICA, LLC

Install in reverse order of removal and note the following:

-- Pay attention to the safety precautions when working with pyrotechnic components. Refer to SAFETY PRECAUTIONS WHEN WORKING WITH PYROTECHNIC COMPONENTS .

-- When installing the front mounting eye -2-, do not pinch the head curtain airbag -1-.

-- Press the head curtain airbag -1- under the screen separator mounting eye -2- as shown in the illustration.
