Wheel Cover, Removing And Installing, Front: Removing

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2024 Audi SQ5, 2024 Audi Q5 e, 2024 Audi Q5, 2023 Audi SQ5, and 2023 Audi Q5 e. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the front wheel spoiler. Refer to FRONT WHEEL SPOILER, REMOVING AND INSTALLING .

-- Q5: loosen the front wheel housing liner in the area of the bumper cover. Refer to FRONT WHEEL HOUSING LINER, REMOVING AND INSTALLING .

-- SQ5: remove the front wheel housing liner. Refer to FRONT WHEEL HOUSING LINER, REMOVING AND INSTALLING .

-- Before product improvement: release the catches -7 to 3- using a flat-head screwdriver in the direction of -arrow- and remove the wheel arch trim -2- from the bumper cover -1-.

Courtesy of AUDI

-- From product improvement: release the retainer -1- and then release the retainers -8 through 4- using a flat-head screwdriver -arrow-.

Courtesy of AUDI

-- Remove the wheel arch trim -3- from the bumper cover -2-.

-- Release the wheel arch trim -2- with the Wedge Set:T10383/1 from the fender -1- and remove.

Courtesy of AUDI
