Right Instrument Panel Ambient Lighting Lamp -L230-, REMOVING AND INSTALLING: Removing
WARNING: This page is about a different car, the 2024 Audi SQ7, 2024 Audi Q7, 2023 Audi SQ7, and 2023 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the lower front passenger side instrument panel decorative trim -2-. Refer to INSTRUMENT PANEL DECORATIVE TRIM, REMOVING AND INSTALLING .
This is disassembled to remove the faulty LED module.
-- Release the retainers in direction of -arrows-, and remove the cover -6-.
-- Remove the circuit board -1-.
-- Release the retainers -3 and 5- and remove the housing -2- from the fiber-optic cable -4-.
