Impact Member, Removing And Installing: Removing
WARNING: This page is about a different car, the 2024 Audi SQ7, 2024 Audi Q7, 2023 Audi SQ7, and 2023 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL, REMOVING AND INSTALLING .
-- Remove the door. Refer to DOOR, REMOVING AND INSTALLING .
-- Pry out the B-pillar cover -3-.
-- Remove the bolts -1, 4 and 5-.
-- Remove the member plate -2-.
-- Remove the impact member -arrow- forward.
-- Release the retainers -arrows- and remove the A-pillar cover -2- from the impact member -1-.
