Trim Molding, Removing And Installing, Engine Compartment Lid: Installing
WARNING: This page is about a different car, the 2024 Audi SQ7, 2024 Audi Q7, 2023 Audi SQ7, and 2023 Audi Q7. However, it is still accessible from the selected car via links, so may be relevant.
Install in the reverse order of removal while noting the following:
- The vehicle and the cover must be at room temperature.
- The adhesive surfaces must be free of dirt and grease.
-- Remove the adhesive residue from the body.
-- Clean the painted side of the adhesive surface with Cleaning Solution and let it dry.
-- Remove the protective film from the adhesive tape -2-.
-- Align the trim molding -1- over the locating pin -3- on the engine compartment lid.
-- Press on the trim molding -1- in the adhesive surface area with the Roller :T40400 .
- Vehicle resting time is at least 60 minutes at room temperature.
