Vibration Damper, Removing And Installing, 2.9L Engine: Removing
WARNING: This page is about a different car, the 2022 Audi Q8, 2021 Audi Q8, 2020 Audi Q8, and 2019 Audi Q8. However, it is still accessible from the selected car via links, so may be relevant.
Preliminary work may be required depending on the model. Refer to VIBRATION DAMPER, REMOVING AND INSTALLING .
-- Remove the generator ribbed belt. Refer to RIBBED BELT FOR GENERATOR, REMOVING AND INSTALLING, 2.9L ENGINE .
-- Remove the ribbed belt tensioner for the A/C compressor. Refer to RIBBED BELT TENSIONER FOR A/C COMPRESSOR, REMOVING AND INSTALLING, 2.9L ENGINE .
-- If still installed, remove the cover, remove the bolt -arrow- and the idler roller.
-- Place the : T40330/4 with : T40330/1 on the vibration damper and secure using the bolt -arrow- (23 Nm); to do so, place the : T40330/3 underneath.
-- Remove the bolt -1-.
-- Remove the bolt -arrow- and remove the counterholder and vibration damper.
