Impact Member, Removing And Installing: Installing
Install in reverse order of removal and note the following:
-- Install the impact member in the sequence: -1 through 5-.
| Step | |
|---|---|
| 1. | -- Insert the impact member into the door. |
| 2. | -- Tighten the screw -4- to 1.5 Nm. |
| 3. | -- Insert the member plate -2- and tighten the screw -1-. |
| 4. | -- Tighten the screws in the following sequence: -4, 5 and 6-. |
| 5. | -- Press on the cover -7- and cap -3- until they audibly lock. |
