GPS Antenna Splitter, Removing And Installing, 7G1/7I1/7I2/IV0: Removing
-- Turn off the ignition and all electrical equipment. Set the ignition key outside of the vehicle.
-- Remove the rear seat. Refer to BENCH SEAT/SINGLE SEAT, REMOVING AND INSTALLING .
-- Remove the rear seat backrest. Refer to REAR SEAT BACKREST, REMOVING AND INSTALLING .
-- Open the wiring harness.
-- Release and disconnect the connectors from the GPS Antenna Splitter -R110- -1-.
-- Remove the GPS Antenna Splitter -R110- -1-.
