Driver And Front Passenger Backrest Adjustment Motor -V45- / -V46-, Removing And Installing: Removing
-- Remove the front seat. Refer to FRONT SEAT, REMOVING AND INSTALLING .
-- Secure the front seat to the :VAS6136 . Refer to FRONT SEAT, MOUNTING ON FIXTURE FOR SEAT REPAIR .
-- Remove the seat frame trim panel on the tunnel side. Refer to TUNNEL-SIDE SEAT FRAME TRIM PANEL, REMOVING AND INSTALLING .
-- Remove the seat frame trim panel on the side sill side. Refer to SEAT FRAME TRIM PANEL ON SIDE SILL SIDE, REMOVING AND INSTALLING .
-- Remove the backrest cover. Refer to BACKREST COVER, REMOVING AND INSTALLING .
-- Disengage the molding for the cover and both hooks -arrows-, and pull the cover back.
-- Mark the left and right angle position of the backrest hinge to the backrest frame with paint -arrows-.
-- Destroy the lock washer -1- and remove it.
-- Push the adjustment shaft -2- to the opposite side out of the backrest frame.
-- Remove the bolt -arrow-.
-- Remove the backrest adjustment motor -2-.
-- Release and disconnect the connector -1- from the removed backrest adjustment motor.
