Rear Seat Belt Latch, Removing And Installing: Removing
WARNING: This page is about a different car, the 2021 Audi S4 and 2021 Audi A4 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the rear bench seat. Refer to BENCH SEAT/SINGLE SEAT, REMOVING AND INSTALLING .
Right Seat Belt Latch with Rear Center Belt End Fitting:
-- Free up and disconnect the connector -4- for the seat belt switch.
-- Remove the nut -1-.
-- Remove the belt end fitting -2- with the seat belt latch -3-.
-- Remove the clip and remove the seat belt latch.
- -arrow- : locating pin on floor panel
Center and Left Seat Belt Latch:
-- Free up and disconnect the connector -1- for the seat belt switch.
-- Remove the nut -4-.
-- Remove the seat belt latches -2 and 3-.
- -arrow- : locating pin on floor panel
Seat Belt Latches, Separating from Each Other:
-- Free up the wires for the seat belt switch.
WARNING:
Risk of eye injury.
- Wear protective eyewear!
-- Drill out the rivet.
