Overview - Rear Lid Tail Lamps

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2022 Audi SQ5, 2022 Audi Q5 e, 2022 Audi Q5, 2021 Audi SQ5, and 2021 Audi Q5 e. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Rear Lid Tail Lamps

Courtesy of AUDI OF AMERICA, LLC

Tail Lamp
- In the rear lid
- Removing and Installing. Refer to REAR LID TAIL LAMP, REMOVING AND INSTALLING .
Nut
- Tightening specification and sequence. Refer to Fig 2.
Grommet
Nut
- Tightening specification and sequence. Refer to Fig 2.
Grommet
Seal
- Replace if damaged
- Self-adhesive
Nut
- Tightening specification and sequence. Refer to Fig 2.
Inner Spacer
- Replace if damaged
- Self-adhesive
Outer Spacer
- Replace if damaged
- Self-adhesive

Tightening Specification and Sequence for the Tail Lamps

Fig 2: Tail Lamps Tightening Sequence

Courtesy of AUDI OF AMERICA, LLC

-- Tighten the nuts for the tail lamps to 3.5 Nm and in the sequence -1, 2 and 3-.
