Overview - Window Guides And Window Shaft Strips, Sedan
WARNING: This page is about a different variant/trim than selected.
- Outer Window Shaft Strip
- Removing and installing. Refer to OUTER WINDOW SHAFT STRIP, REMOVING AND INSTALLING
- Window Guide
- Removing and Installing. Refer to WINDOW GUIDE, REMOVING AND INSTALLING, SPORTBACK .
- Door
- Inner Window Shaft Strip
- Removing and installing. Refer to INNER WINDOW SHAFT STRIP, REMOVING AND INSTALLING
- Bolt
- 3.5 Nm
- Quantity: 2
- Guide Rail
- For the door window
- Removing and installing. Refer to DOOR WINDOW GUIDE RAIL, REMOVING AND INSTALLING
