Rear Parking Aid Warning Buzzer -H15-, Removing And Installing: Removing
WARNING: This page is about a different car, the 2017 Audi A3, 2016 Audi A3, and 2015 Audi A3. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the right D-pillar trim panel. Refer to PASSENGER COMPARTMENT TRIM or refer to the appropriate service information .
-- Remove the bolts -1 and 3-.
-- Remove the rear parking aid warning buzzer -2- with the expanding clip.
-- Disconnect the connector -4-.
-- Remove the right side trim panel. Refer to SIDE TRIM PANEL, REMOVING AND INSTALLING .
-- Remove the bolts -2 and 4-.
Depending on vehicle equipment the parking aid warning buzzer can also be installed in the side trim panel.
-- Remove the rear parking aid warning buzzer -3- with the expanding clip.
-- Disconnect the connector -1-.
