Overview - Door
WARNING: This page is about a different variant/trim than selected.
- Door Arrester
- Removing and Installing. Refer to DOOR ARRESTER, REMOVING AND INSTALLING .
- Bolt
- 33 Nm
- Cap
- For the door arrester
- Note the installation direction
- Bolt
- 45 Nm
- Bolt
- 8 Nm
- Quantity: 2
- Door
- Removing and Installing. Refer to DOOR, REMOVING AND INSTALLING .
- Support
- Market-Specific Version
- Bolt
- 10 Nm
- Bolt
- 32 Nm
- Door Hinge
- Upper
- Stud Bolt
- 23 Nm
- Cap
- Place on the stud bolt.
- Bolt
- 32 Nm
- Bolt
- 32 Nm
- Door Hinge
- Lower
- Bolt
- 32 Nm
- Stud Bolt
- 23 Nm
- Cap
- Place on the stud bolt
- Bolt
- 45 Nm
