Overview - Sill Panel Strip
WARNING: This page is about a different variant/trim than selected.
- Clip
- Replace damaged or deformed clips
- Insert in the sill panel strip
- Remove any remaining clips in the body mounting points using the Omega Clip Tool: T40280 . To install, insert into the sill panel strip.
- Quantity: 5
- Clip
- Replace a damaged or deformed clip
- Insert in the sill panel strip
- Sill Panel Strip
- Removing and installing. Refer to SILL PANEL, REMOVING AND INSTALLING .
- Engage the sill panel in the side trim panel.
- Press on until it engages audibly
- Stretch the door seal lip over
