Overview - C-Pillar Trim Panel
WARNING: This page is about a different variant/trim than selected.
- Rear Seat Belt Guide
- Removing and installing. Refer to REAR SEAT BELT GUIDE, REMOVING AND INSTALLING .
- C-Pillar Trim Panel
- Removing and installing. Refer to C-PILLAR TRIM PANEL, REMOVING AND INSTALLING .
- Press on until it engages audibly
- Stretch the rear lid seal lip
- Clip
- Replace damaged or deformed clips
- Remove any remaining clips in the body mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Insert in the trim panel
- Quantity: 2
- Bolt
- 8 Nm
