Overview - Rear Lid Upper Trim Panel
WARNING: This page is about a different variant/trim than selected.
- Side Clamp
- Replace damaged or deformed clips
- Remove any remaining clips in the rear lid mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Insert in the trim panel
- Quantity: 3 on the left and right side
- Side Rubber Buffer
- Insert in the trim panel
- Quantity: 2 on the left and right side
- Rear Lid Upper Trim Panel
- Removing and installing. Refer to REAR LID UPPER TRIM PANEL, REMOVING AND INSTALLING .
- Press on until it engages audibly
- Upper Rubber Buffer
- Insert in the trim panel
- Quantity: 4
- Upper Clip
- Remove any remaining clips in the rear lid mounting points using the Omega Clip Tool: T40280 . To install, insert into the trim panel.
- Replace damaged or deformed clips
- Insert in the trim panel
- Quantity: 4
- Expanding Clip
- Remove using the Clip Pliers: T40172A
- Quantity: 1 on the left and right side
