Button Trim, Removing And Installing: Removing

WARNING: This page is about a different variant/trim than selected.

GWWA70-12167

Courtesy of AUDI OF AMERICA, LLC

-- Remove the door trim panel. Refer to FRONT DOOR TRIM PANEL, REMOVING AND INSTALLING .

-- Remove the insulation mat.

-- Remove the armrest. Refer to FRONT ARMREST, REMOVING AND INSTALLING .

-- Remove the pull handle. Refer to FRONT PULL HANDLE, REMOVING AND INSTALLING .

-- Remove the power window switch. Refer to POWER WINDOW CONTROL HEAD IN DRIVER DOOR -E512-, REMOVING AND INSTALLING .

-- Remove the bolts -1- on the rear of the door trim.

-- Remove the trim -2- from the door panel.
