Luggage Compartment Lamp, Removing And Installing: Removing

WARNING: This page is about a different variant/trim than selected.

-- Remove the luggage compartment side trim panel. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING .

-- Remove the cover -3- from the luggage compartment side trim panel -1-.

Courtesy of AUDI OF AMERICA, LLC

NOTE:

Ignore item -2-.

-- Release the retainers in direction of -arrows- and free up the connector.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the luggage compartment lamp -1- from the cover -2-.
