Component Location Overview - Center Console Lamps
WARNING: This page is about a different variant/trim than selected.
- Multimedia System Control Head Contour Illumination Lamp 1 -L233-
- If an LED is faulty, then the multimedia system control head must be replaced
- Selector Lever Transmission Range Position Display Unit -Y26-
- Removing and installing. Refer to Selector Lever Transmission Range Position Display Unit -Y26-, REMOVING AND INSTALLING .
- Storage Compartment Lamp
- Removing and installing. Refer to STORAGE COMPARTMENT LAMP, REMOVING AND INSTALLING .
- Fiber-Optic Cable for Ambient Lighting Lamp
- Removing and installing. Refer to FIBER-OPTIC CABLE FOR FRONT CENTER CONSOLE AMBIENT LIGHTING BULB -L193- / -L194-, REMOVING AND INSTALLING .
- Front Center Console Ambient Lighting Bulb 1 -L193-
- Removing and installing. Refer to FRONT CENTER CONSOLE AMBIENT LIGHTING BULB -L193- / -L194-, REMOVING AND INSTALLING .
- Front Center Console Ambient Lighting Bulb 2 -L194-
- Removing and installing. Refer to FRONT CENTER CONSOLE AMBIENT LIGHTING BULB -L193- / -L194-, REMOVING AND INSTALLING .
- Fiber-Optic Cable for Ambient Lighting Lamp
- Removing and installing. Refer to FIBER-OPTIC CABLE FOR FRONT CENTER CONSOLE AMBIENT LIGHTING BULB -L193- / -L194-, REMOVING AND INSTALLING .
