Bumper Antennas, Removing And Installing: Removing
WARNING: This page is about a different variant/trim than selected.
-- Remove the rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
Right Rear Bumper Antenna
-- Release and disconnect the connector -3-.
-- Remove the nut -arrow- on the bumper antenna -1-.
-- Remove the bumper antenna -1- from the bracket -2-.
-- Remove the nuts -arrow- for the bracket -2-.
-- Remove the bracket -2- from the body.
Left Rear Bumper Antenna
-- Release and disconnect the connector -3-.
-- Remove the nut -arrow- on the bumper antenna -1-.
-- Remove the bumper antenna -1- from the bracket -2-.
-- Remove the nuts -arrows- for the bracket -2-.
-- Remove the bracket -2- from the body.
