Overview - Body Tail Lamps
WARNING: This page is about a different variant/trim than selected.
- Tail Lamp
- There are different versions. Refer to the Parts Information for the correct allocation.
- Removing and installing. Refer to TAIL LAMP, REMOVING AND INSTALLING .
- Clip Nut
- Quantity: 2
- Clip
- Cover
- For the tail lamp
- Removing and installing. Refer to TAIL LAMP, REMOVING AND INSTALLING .
- Adjuster
- Screw
- 3.5 Nm
- Screw
- 3.5 Nm
- Adjuster
