Overview - High-Mounted Brake Lamp
WARNING: This page is about a different variant/trim than selected.
- Nut
- 2.5 Nm
- Quantity: 2
- Seal
- Replace if damaged
- There are different versions. Refer to the Parts Information.
- Quantity: 2
- Seal
- Replace if damaged
- There are different versions. Refer to the Parts Information.
- Quantity: 4
- High-Mounted Brake Lamp
- With High-Mounted Brake Lamp Bulb -M25-
- Removing and Installing. Refer to HIGH-MOUNTED BRAKE LAMP, REMOVING AND INSTALLING .
- Grommet
- Replace if damaged
- Quantity: 4
