Overview - Bulkhead
WARNING: This page is about a different variant/trim than selected.
- Plenum Chamber Insulation
- Metal Nut
- Quantity: 2
- Bolt
- 2.5 Nm
- Seal
- Plenum Chamber Bulkhead
- Removing and Installing. Refer to PLENUM CHAMBER BULKHEAD, REMOVING AND INSTALLING .
- Nut
- 8 Nm
- Cover
- For the plenum chamber bulkhead
- Removing and Installing. Refer to PLENUM CHAMBER BULKHEAD COVER, REMOVING AND INSTALLING .
- Expanding Rivet
- Quantity: 2
