Overview - Pneumatic System
WARNING: This page is about a different variant/trim than selected.
- Pneumatic Line
- To remove the compressor press the release ring.
- Attaching. Refer to PNEUMATIC LINES, DISCONNECTING AND CONNECTING .
- O-Ring
- Replace after removing
- Driver Multi-Contour Seat Compressor -V439-
- Front passenger side: Front Passenger Multi-Contour Seat Compressor -V440-
- Removing and installing. Refer to Driver Multi-Contour Seat Compressor -V439- /Front Passenger Multi-Contour Seat Compressor -V440-, REMOVING AND INSTALLING .
- Bracket
- For the multi-contour seat compressor
- Bolt
- 2.5 Nm
- Quantity: 2
- Clip
- Replace after removing
- Air Cushion
- For the backrest bolster adjuster
- Removing and installing. Refer to BACKREST BOLSTER ADJUSTER AIR CUSHION, REMOVING AND INSTALLING .
- Clip
- Replace after removing
- Spring Mat
- Driver Multi-Contour Seat Control Module -J873-
- Front passenger side: Front Passenger Multi-Contour Seat Control Module -J872-
- Allocation. Refer to the Parts Information.
- Removing and installing. Refer to BACKREST BOLSTER ADJUSTER AIR CUSHION, REMOVING AND INSTALLING .
- Air Cushion
- For the lumbar support
- Removing and installing. Refer to LUMBAR SUPPORT AIR CUSHION, REMOVING AND INSTALLING .
