Rear View
WARNING: This page is about a different variant/trim than selected.
NOTE:
-Arrow- = direction of travel
Refer to OVERVIEW - HEATER AND A/C UNIT .
- CoverNOTE:
There are currently no air ducts installed in the center console and in the rear footwell on the Audi TT (like on the Audi A3, for example). These openings in the heater and A/C unit are therefore sealed off by a cover.
- Operating Lever
- For operating the vent doors
- Activated via the adjuster
- Left Door for Left Instrument Panel Vent
- Left Door for Center Instrument Panel Vent
- Right Door for Right Instrument Panel Vent
- Right Door for Center Instrument Panel Vent
